Ice on the suction line in Wellborn in August: how a coil freezes in 94-degree heat

The call

A Thursday in August, mid-morning, from a manufactured home on acreage a few miles outside Wellborn. The owner had noticed the house creeping warmer for three days. That morning she went outside and found the big insulated copper line into the package unit wearing a sleeve of white frost, in 90-degree heat, with water puddling under it. She had already done the right thing without knowing it: turned the cooling off because it obviously was not working.

We asked her to leave the fan running and start the thaw, told her the honest drive time from Palm Coast, and loaded the crawlspace gear along with the gauges.

What we found

By the time the truck arrived the frost outside had melted. The indoor coil compartment told the story: the coil had been a block of ice and was still dripping into an overflowing pan. The filter at the return grille was gray and bowed inward. The pressures on the gauges were low on the suction side, which fits a frozen coil but does not say why.

So we went under the home. The belly duct, the insulated trunk that runs the length of a manufactured home under the floor, had torn open near the center and was lying on the ground. Half the air the blower moved was being dumped into the crawlspace instead of returning across the coil. The coil was being asked to cool a trickle of air, ran too cold, and froze. The clogged filter made it worse. The refrigerant charge, once the coil was thawed and airflow restored, was correct.

Three days of ice, one torn duct.

The fix

• Finished the thaw with the fan running, then cleared the drain and pan. The condensate line had scale in it from the well water and was flushed and treated.
• Reconnected and sealed the belly duct, replaced the torn section and the sagging vapor barrier, and strapped it back up to the floor joists.
• Replaced the filter and upgraded the return grille to hold a deeper one.
• Checked the charge again with full airflow and found it within specification; no refrigerant added.
• Added a float switch so the next drain problem shuts the system off instead of flooding the floor.

The system was cooling normally that afternoon. The homeowner had been quoted a new unit by a neighbor’s cousin.

Call about a frozen system

Why this county freezes more coils than it should

Live Oak’s July afternoons are the hottest in north Florida, so systems run near their limits for months. Add the local housing: nearly half the county lives in manufactured homes with thin belly ducts that tear, sag and soak, and most of the rest live in 1960s-1990s houses with original attic flex that has pulled loose at the joints. Starved airflow is everywhere. Then there is the pollen: a filter installed in November is choked by March. And refrigerant leaks do their share, especially in older systems that took a lightning surge or ran on rough generator power after Idalia.

Keeping the ice away

Change the filter in March after the pines and again in late summer. Have the belly or attic ducts looked at every maintenance visit, and after any flooding or animals under the home. Keep the return grilles unblocked by furniture. If the air at the vents goes weak before it goes warm, call then, before the coil freezes solid and the pan overflows. And if anyone offers to add refrigerant without finding where the last charge went, decline.
